CCT air conditioner for Comfort and Aspect helmets

The CCT air conditioner  is dedicated to regulating the temperature of the breathing air supplied to Comfort and Aspect helmets.

The air conditioner warms up or cools down the breathing air supplied to protect the respiratory system from air compressors. It ensures the correct inflow of breathing air necessary to guarantee  safe work in the helmet.

The CCT is meant to warm up or cool down the air directed inside the Contracor air helmets, making the work all the more comfortable both in summer and winter.

Technical specifications

Usage of the Contracor CCT Air Conditioner does not interfere with the protection factor NPF.

Operating pressure

minimum: 2.5 bar

maximum: 5.0 Bar

most effective range: 4.5 – 5.0 bar

Minimum airflow with regulator at 2,5 bar working pressure and hose length 40m: 165 Nl/min

Maximum airflow with regulator at 5,0 bar working pressure and hose length 40m: 320 Nl/min

Minimum ambient temperature -10 °C

Maximum ambient temperature: +60 °C

Maximum BAH breathing air supply hose length: 40 m

Noise level at 5.0 bar and maximum air flow: 90 dB(A)

Weight on the belt: 400 g
